    12n Stepper 12nm Motor Kit Cnc Nema 34 Servo Motor With Digital Controller

    Ask Lasest Price
    Brand Name : JSS
    Model Number : 86HS156
    Certification : CE ROHS ISO
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 10000pcs/month
    Delivery Time : 10-15days
    • Product Details
    • Company Profile

    12n Stepper 12nm Motor Kit Cnc Nema 34 Servo Motor With Digital Controller

    12N Stepper 12Nm Motor Kit Cnc Nema 34 Driver High Torque Motor Kits With Digital Controller


    A Nema 34 stepper motor is a stepper motor with a 3.4 x 3.4 inch (86 x 86 mm) faceplate. Nema 34 high torque stepper motors deliver great value with no quality sacrifice. These motors are engineered to provide the highest possible torque but minimize vibration and audible noise.

    12n Stepper 12nm Motor Kit Cnc Nema 34 Servo Motor With Digital Controller


    Model No.
    Step Angle(°)
    Rated Voltage(V)
    Rated Current(A)
    Phase Resistance(Ω)
    Phase Inductance(mH)
    Holding Torque(Kg.cm)
    Motor Length(MM)
    Lead Wires No.
    Motor Weight(Kg)
    86HS65-3004
    1.8
    3.3
    3
    1.1
    6.5
    28
    65
    4
    1.7
    86HS78-4004
    1.8
    1.5
    4
    0.38
    2.5
    35
    78
    4
    2.3
    86HS78-4204
    1.8
    1.9
    4.2
    0.45
    4
    45
    78
    4
    2.3
    86HS82-4504
    1.8
    1.4
    4.5
    0.32
    2.8
    45
    82
    4
    2.5
    86HS100-5004
    1.8
    2.5
    5
    0.5
    4
    68
    100
    4
    3.2
    86HS118-6004
    1.8
    3.6
    6
    0.6
    6
    85
    118
    4
    3.7
    86HS156-6204
    1.8
    3.6
    6.2
    0.75
    9
    12
    156
    4
    5.5

    12n Stepper 12nm Motor Kit Cnc Nema 34 Servo Motor With Digital Controller
