Changzhou Jinsanshi Mechatronics Co., Ltd
5 Years
| Ask Lasest Price | |
| Brand Name : | JSS |
| Model Number : | 20HSL30-0604 |
| Certification : | CE SGS |
| Price : | USD 8-9 pcs |
| Payment Terms : | L/C, T/T, Western Union |
| Supply Ability : | 100000 pcs month |
| Delivery Time : | 5-10 days |
Stepper motors divide each full rotation into a number of equally sized steps. Also known as step or stepping motors, these 2-phase brushless DC motors offer quick, precise load positioning and exceptional holding torque at any of these incremental steps. Each step represents 1.8°, or 200 steps per revolution. When using a microstepping drive, each 1.8° step can be broken into even smaller increments to achieve nearly servo-like positioning performance—without the need for complex feedback devices or a closed-loop control system.
Motor Specification
| Model No | Step Angle(°) | Rated Voltage(V) | Rated Current (A) | Phase Resistance(Ω) | Phase Inductance (mH) | Holding Torque (g.cm) | Rotor Inertia (g.cm²) | Motor Length (mm) | Leads No. | Motor Weight(g) |
| 20HS28-0204 | 1.8 | 4.6 | 0.2 | 23 | 8.2 | 140 | 2.5 | 28 | 4 | 50 |
| 20HS30-0506 | 1.8 | 5.75 | 0.5 | 11.5 | 1.7 | 180 | 2.8 | 30 | 6 | 60 |
| 20HS33-0604 | 1.8 | 3.9 | 0.6 | 4.5 | 1.6 | 180 | 3.2 | 33 | 4 | 70 |
| 20HS38-0604 | 1.8 | 6 | 0.6 | 10 | 5.5 | 260 | 3.6 | 38 | 4 | 80 |
| 20HS42-0804 | 1.8 | 1.2 | 0.8 | 1.5 | 5.4 | 300 | 4 | 42 | 4 | 90 |
Lead screw Specification
| Diameter | Lead Distance mm | Start | Step length mm | Applicable Motor |
| M5 | 1.6 | 2 | 0.008 | 20HSL-E |
| Tr5*2 | 2 | 2 | 0.01 | 20HSL-E |
| Tr6.5 | 3 | 2 | 0.015 | 20HSL-E |
Motor Dimension
.
|
|
