Changzhou Jinsanshi Mechatronics Co., Ltd
5 Years
| Ask Lasest Price | |
| Brand Name : | JSS-MOTOR |
| Model Number : | 110HCE16N-B39+3HSS2206 |
| Certification : | CE,ROHS,ISO |
| Price : | USD180-USD280 |
| Payment Terms : | T/T,Paypal,credit card, Western Union |
| Supply Ability : | 200pcs per weeks |
| Delivery Time : | 10 work days |
nema 42 16NM high torqur model high voltage easy servo motor driver with screen display 3000rpm speed
Our stepper motors are widely used in stage lighting control, security surveillance, home appliance, video equipment, laserworkstation, carving machine, automotive, office automation, smart toy, digital controlled machinery and medical instrument.
NEMA42 Easy Servo Series(NEMA42 Closed Loop series)
| Mode | Step angle | Current (A) | Resistance (Ω±10%) | Inductance (mH±20%) | Holding torque(N.m) | Motor length(mm) | Encoder Resolution(PPR) | Applicable Driver |
| 110HCE12N-B39 | 1.2° | 4.2 | 1.2 | 13 | 12 | 139 | 1000 | 3HSS2260 |
| 110HCE12N-B39 | 1.2° | 6.4 | 0.9 | 9.5 | 16 | 180 | 1000 | 3HSS2260 |
| 110HCE20N-B39 | 1.2° | 4.2 | 1.88 | 18 | 20 | 221 | 1000 | 3HSS2260 |
Motor Eelctrical Parameters:
Close Loop Driver 3HSS2260
Features
1, 32-bit DSP and vector closed-loop control technology
2, Without losing step, high accuracy in position
3, Improve the motor output torque and working speed
4, Variable current control technology, restrain motor temperature
rise
5, Adapt to variety of mechanical load conditions(including
low-rigidity pulleys), no
need to adjust the gain parameter
6, Smooth and reliable moving, low vibration, great improvement in
accelerate and
decelerate
7, The ability of zero speed static without vibration
8, Adapt to 3-phase 86(NEMA34) and 110(NEMA 42) hybrid servo motor
9, Maximum step-pulse frequency 200KHZ
10, Micro step 400-60000 pulse/rev
11, Voltage range AC150-240V
12, Over current, over voltage and over position protection
13, Six digital tube display, easy to set parameters and monitor
the motor running
state
Driver installation size: (mm)
Driver dimension (mm):
Wiring Diagram:
Packing and shipment:
We have standard package for our products. We can also make it as per your special requirements.
Shipping can be arranged as per your requirements.
1. By sea
2. By Air
3. By Express, like DHL, Fedex, UPS etc.
Changzhou Jinsanshi mechatronics Co., Ltd., exporting stepper motors, servo motor,spindle motor,BLDC motor and their driver ,VFD. We spcialize in this field for many years, with the strength of high quality and competitive price in China.
We have our own techinical department and we developed various
models of stepper motor, we also have complete drawings for our
motors.
We can provide complete technical proposal for your project.
Any question about stepper motor, please contact me online or send
me mail. We will reply you within 2 days!
our certification:
|
|
