Engraving Machine Stepper Motor Driver Stepper Motor Controller 24-80VAC DM860A

Advantages:
High torque, low heating, low vibration, low cost, We also use high quality chips, with long using life. We have our own driver reserach and development department, we can provide professional technical support and accept customize.

Digital hybrid stepper motor driver
Features:
1.The DM860D is a new generation high-performance digital stepper driver based on DSP and PID control algorithm with microstep control technology.
2.The motors driven by DM860A can run with much smaller noise and much less vibration than other drivers in the market.
3.The DM860A possess the feature of lower noise, lower vibration, and lower heating.
4.The DM860A’s voltage is AC24V-80V or DC30-110V.
5.It is suitable for all the 2-phase hybrid stepper motor whose current is less than 7.2A.
6.There are 16 kinds of microstep of DM860A.
7.The maximum step number of DM860A is 51200 steps/rev (microstep is 1/256 ).
8.Its current range 2.0A-7.2A, and its output current has 8 stalls.
9.DM860A has automatic semi-flow, over-voltage, under voltage and over-current protection function.​

10. Suitable for nema 34 and nema 42 stepper motor.

Current selection

Microstep Selection:

Alarming:

Dimensions:

Application:
